OPENTEC FMF100

Capacity/Panel: 100 kg
Panel thickness: 70 mm
Profils: 60 mm min
Max opening dimensions: 6 x 2.4 m (3+5 panels)
Track: Aluminium
Movement: Folding

Folding system for metal-framed picture windows. For panels of 50 to 100 mm thinckness. For outside use: Restaurants, hotels, patios, bars, shopping centres, etc...

  • Folding system for creating a tightly sealed metal-framed picture window
  • Choice of structural materials: anodised aluminium and stainless steel
  • Convenient to use: picture window slides easily
  • Advantage: unique design to adapt to slim profiles for aesthetic and maximum visibility
  • 3 panels min.
OPENTEC FMF100 - Image 1 OPENTEC FMF100 - Image 2

Choose your Tracks and brackets

2 product(s)

Choose your Pelmets and end caps

4 product(s)
  • Set of end caps

    Set of end caps

    Ref: GH10430EN

    Set of black raw plastic end caps for pelmets (GH10430P). End caps can be painted on request in your choice of RAL colour.

  • Set of pelmet mounts

    Set of pelmet mounts

    Ref: GH10430BP

    Set of 4 black plastic pelmet brackets (GH10430P). Fastened to track 10400A if track is wall-mounted.

  • Aluminium pelmet - 6 m

    Aluminium pelmet – 6 m

    Ref: GH10430P

    Clip-on raw aluminium pelmet. For track 10400A. Used for wall mounting - Height = 78.5 mm - Length = 6 m. Pelmets can be painted on request in your choice of RAL colour.

  • Aluminium pelmet - 3 m

    Aluminium pelmet – 3 m

    Ref: GH10430P/3

    Clip-on raw aluminium pelmet. For track 10400A. Used for wall mounting - Height = 78.5 mm - Length = 3 m. Pelmets can be painted on request in your choice of RAL colour.

Choose your Hangers

2 product(s)

Choose your Split hinges

7 product(s)
  • Hinge

    Hinge

    Ref: 1512GJSO

    Weld-type split hinge, between two doors. Pin Ø = 12 mm.

  • Hinge

    Hinge

    Ref: 1512GJSOF

    Weld-type split hinge, between door and frame. Pin Ø = 12 mm.

  • Hinge

    Hinge

    Ref: 1512SO3D

    Weld-type split hinge, between two doors. Adjustable for the 3 dimensions. Pin Ø = 12 mm.

  • Hinge

    Hinge

    Ref: 1512SOF3DD

    Weld-type split hinge, between door and frame. Mounted on the right of the opening, (when you are on the track side). Adjustable for the 3 dimensions. Pin Ø = 12 mm.

  • Hinge

    Hinge

    Ref: 1512SOF3DG

    Weld-type split hinge, between door and frame. Mounted on the left of the opening, (when you are on the track side). Adjustable for the 3 dimensions. Pin Ø = 12 mm.

  • Hinge

    Hinge

    Ref: 1512SOFG

    Weld-type split hinge (with lubricator), between door and frame. Pin Ø = 12 mm.

  • Hinge

    Hinge

    Ref: 1512SOG

    Weld-type split hinge (with lubricator), between two doors. Pin Ø = 12 mm.

Choose your Lower profile

7 product(s)

Choose your Accessories

6 product(s)
