OPENTEC FMF150

OPENTEC FMF150

Capacity/Panel: 150 kg
Panel thickness: 50 to 100 mm
Profils: 120 mm min
Max opening dimensions: 16.5 x 3.5 m (7+8 panels)
Track: Aluminium
Movement: Folding

Folding system for metal-framed picture windows. For panels of 50 to 100 mm thinckness. For outside use: Restaurants, hotels, patios, bars, shopping centres, etc...

  • Folding system for creating a tightly sealed metal-framed picture window
  • Choice of structural materials: anodised aluminium and stainless steel
  • Convenient to use: picture window slides easily
  • 3 panels min.
* Number of cycles* Fabrication* 12 years guarantee
OPENTEC FMF150 - Image 1 OPENTEC FMF150 - Image 2 OPENTEC FMF150 - Image 3

Choose your Tracks and brackets

3 product(s)

Choose your Pelmets and end caps

4 product(s)
  • Pelmet - 3 m

    Pelmet – 3 m

    Ref: GJ10530P/3

    Clip-on raw aluminium pelmet. For track 10500A. Used for wall mounting - Height = 105 mm - Length = 3 m. Pelmets can be painted on request in your choice of RAL colour.

  • Pelmet - 6 m

    Pelmet – 6 m

    Ref: GJ10530P

    Clip-on raw aluminium pelmet. For track 10500A. Used for wall mounting - Height = 105 mm - Length = 6 m. Pelmets can be painted on request in your choice of RAL colour.

  • Set of pelmet mounts

    Set of pelmet mounts

    Ref: GJ10530BP

    Set of 4 black plastic pelmet mounts (GJ10530P). Fastened to track 10500A if track is wall-mounted.

  • Set of end caps

    Set of end caps

    Ref: GJ10530EN

    Set of black raw plastic end caps for GJ10530P pelmets. End caps can be painted on request in your choice of RAL colour.

Choose your Hangers

3 product(s)
  • Hanger set

    Hanger set

    Ref: GJ10530EHL

    Left-side end hanger set including:
    - 1 left-side end hanger
    - 1 lower end-guide

  • Hanger set

    Hanger set

    Ref: GJ10530EHR

    Right-side end hanger set including:
    - 1 right-side end hanger
    - 1 lower right-side end-guide

  • Hanger set

    Hanger set

    Ref: GJ10530IH

    Intermediate hanger set including:
    - 1 intermediate hanger
    - 1 lower intermediate guide

Choose your Split hinges

11 product(s)
  • Hinge

    Hinge

    Ref: 1514SOR

    Weld-type adjustable split hinge. Ø 14 mm.

  • Hinge

    Hinge

    Ref: 1514GJOSO

    Weld-type split hinge. Ø 14 mm.

  • Hinge

    Hinge

    Ref: 1514GJSOL

    Weld-type adjustable offset split hinge. Ø = 14 mm. Opening to the left.

  • Hinge

    Hinge

    Ref: 1514GJSOR

    Weld-type adjustable offset split hinge. Ø = 14 mm. Opening to the right.

  • Set of hinges

    Set of hinges

    Ref: GJ10530HOL

    Set of 3 weld-type split-hinges, opening to the left, including:
    - 2 weld-type adjustable offset split-hinges. Ø 14 mm. (1514GJSOL)
    - 1 weld-type hinge. Ø 14 mm. (1514GJOSO)

  • Set of hinges

    Set of hinges

    Ref: GJ10530HOR

    Set of 3 weld-type split-hinges, opening to the right, including:
    - 2 weld-type adjustable offset split-hinges. Ø 14 mm. (1514GJSOR)
    - 1 weld-type hinge. Ø 14 mm. (1514GJOSO)

  • Set of hinges

    Set of hinges

    Ref: GJ10530HS

    Set of 3 weld-type adjustable split-hinges. Ø 14 mm. (1514SOR).

  • Welding jig

    Welding jig

    Ref: GJ10530GS-1

    Welding jig for weld-type split-hinge (GJ10530EHL and GJ10530EHR).

  • Welding jig

    Welding jig

    Ref: GJ10530GS-2

    Welding jig for weld-type split-hinge (1514GJOSO, 1514GJSOL and 1514GJSOR).

  • Welding jig

    Welding jig

    Ref: GJ10530GS-4

    Welding jig for weld-type adjustable split-hinge (1514SOR).

  • Pin kit

    Pin kit

    Ref: GJ10530GS-5

    Ø9, Ø10 and Ø11 mm pin kit for adjusting the clearance between panels.

Choose your Lower profile

7 product(s)

Choose your Accessories

5 product(s)
