200 & 2200 series - Capacity door 80 KG

200 & 2200 series - Capacity door 80 KG

Capacity/Door: 80 kg
Track: 3530
Movement: Straight

Easy and long-lasting running.

  • Stable system : the hangers are designed to be constantly in contact with the track.
  • All hangers are electrolytically treated.
  • The 235 A and 235D hangers mounted on roller cages are a unique Mantion system.
  • The hanger 2235 is mounted on ball bearings.
  • Hangers can be mounted in 2 different ways : on the side or on the top.
* Number of cycles* Fabrication* 12 years guarantee
200 & 2200 series – Capacity door 80 KG - Image 1 200 & 2200 series – Capacity door 80 KG - Image 2 200 & 2200 series – Capacity door 80 KG - Image 3

Choose your Accessories

1 product(s)

Choose your Kit

4 product(s)
  • Gear

    Gear

    Ref: 3530GVP-3

    Gear for a door of max 80 kg and max 1.5 m opening, includes:

    • 2 edge-mounted hangers 0235D with 2 nylon rollers mounted in a roller frame;
    • 2 plates for edge mounting 0036;
    • 5 box brackets 3531;
    • 5 screw-in angle plates 3533;
    • 2 end caps 3540;
    • 1 screw-in lower guides 1092V25;
    • 2 stops 1086;
    • 1 handle 1298.

    Assembled WITHOUT a U-profile: double olive lower guide.

    Order separately: 1 track 3530/300.

  • Gear

    Gear

    Ref: 3530GVP-4

    Gear for a door of max 80 kg and max 2 m opening, includes:

    • 2 edge-mounted hangers 0235D with 2 nylon rollers mounted in a roller frame;
    • 2 plates for edge mounting 0036;
    • 7 box brackets 3531;
    • 1 joining bracket 3531MC;
    • 8 screw-in angle plates 3533;
    • 2 end caps 3540;
    • 2 screw-in lower guides 1092V25;
    • 2 stops 1086;
    • 1 handle 1298.

    Assembled WITHOUT a U-profile: double olive lower guide.

    Order separately: 2 tracks 3530/200.

  • Gear

    Gear

    Ref: 3530GVU-3

    Gear for a door of max 80 kg and max 1.5 m opening, includes:

    • 2 edge-mounted hangers 0235D with 2 nylon rollers mounted in a roller frame;
    • 2 plates for edge mounting 0036;
    • 5 box brackets 3531;
    • 5 screw-in angle plates 3533;
    • 2 end caps 3540;
    • 2 screw-in olive lower guides 1102;
    • 2 stops 1086;
    • 1 handle 1298.

    Assembled WITH a U-profile: single olive lower guide.

    Order separately: 1 track 3530/300 and 1 U profile 1109/200.

  • Gear

    Gear

    Ref: 3530GVU-4

    Gear for a door of max 80 kg and max 2 m opening, includes:

    • 2 edge-mounted rollers 0235D with 2 nylon rollers mounted in a roller frame;
    • 2 plates 0036 for edge mounting;
    • 7 box brackets 3531;
    • 1 joining bracket 3531MC;
    • 8 screw-in angle plates 3533;
    • 2 end caps 3540;
    • 2 screw-in olive lower guides 1102;
    • 2 stops 1086;
    • 1 handle 1298.

    Assembled WITH a U-profile: single olive lower guide.

    Order separately: 2 tracks 3530/200 and 1 U profile 1109/200.

Choose your Bottom guide

1 product(s)
  • Guide

    Guide

    Ref: 1102

    Guide with 1 nylon olive on screw plate for 25 x 18 U-profile 1109A.

Choose your Hangers

1 product(s)

Choose your Hangers and Accessories

8 product(s)
  • Hanger

    Hanger

    Ref: 0235A

    Hanger, top fixing with 2 steel wheels mounted on roller cages. Capacity per door: 80kg.

    2 per pack.

  • Hanger

    Hanger

    Ref: 0235D

    Hanger, top fixing with 2 Delrin wheels mounted on roller cages. Capacity per door: 80kg.

    2 per pack.

  • Hanger

    Hanger

    Ref: 2232

    Hanger with swan-neck, with 4 steel wheels mounted on ball bearings. Capacity per door: 80kg.

    2 per pack.

  • Hanger

    Hanger

    Ref: 2235

    Hanger top fixing, with 4 steel wheels mounted on ball bearings. Capacity per door: 80kg.

    2 per pack.

  • Plate

    Plate

    Ref: 0036
    • Top-fixing screwing plate Ø M10
  • U-plate

    U-plate

    Ref: 0036W
    • "U" plate for side fixing, Ø M 10.
  • Angle plate

    Angle plate

    Ref: 0037
    • Angle plate for side fixing, Ø M 10.
  • Apron set

    Apron set

    Ref: 0031
    • Adjustable apron set, 25 to 35 mm thickness. Capacity : 40 Kg

Choose your Fixing plates

6 product(s)

Choose your Profiles

3 product(s)

Choose your Tracks

3 product(s)

Choose your Tracks and brackets

9 product(s)
