9300 series - Weight per panel: 75 Kg | Mantion

Weight per panel: 75 kg
Track: 9030
Movement: Lateral

These hangers are especially designed for lateral sliding doors with a tubular track.

Hangers with 5 different capacities corresponding to 5 different track sections.

* Fabrication

* 12 years guarantee

9300 series – Weight per panel: 75 Kg - Image 1

9300 series – Weight per panel: 75 Kg - Image 2

9300 series – Weight per panel: 75 Kg - Image 1

9300 series – Weight per panel: 75 Kg - Image 2

Track – 2 m

Ref: 9030/200

Galvanised track: 35 x 40 mm, length, 2m.

View product
Track – 3 m

Ref: 9030/300

Galvanised track: 35 x 40 mm, length, 3m.

View product
Track

Ref: 9030/400
- Galvanised track: 35 x 40 mm, length, 4m
View product
Track

Ref: 9030/500
- Galvanised track: 35 x 40 mm, length, 5m
View product
Track

Ref: 9030/600

Galvanised track: 35 x 40 mm, length, 6m.

View product
Track

Ref: 9030N/600

Track 9030 in black STEEL: 35 x 40mm, length, 6 m

View product

Curve

Ref: 9030C
- Untreated, black track: 35 x 40, length, 6m
View product
Curve

Ref: 1111C
- U-curve galvanized,30 x 30. R = 600 mm - For max. 650 mm panels
View product

Hanger

Ref: 9332
- Intermediate hanger with hinge (capacity : 75 kg)
View product
Hanger

Ref: 9332E

Offset end hanger (capacity : 75 kg)

View product

Hinge

Ref: 1512C
- Screwing hinge 85 x 85, with a Ø 12 axle, top-fixing, for woods of 35 mm thick
View product

U-profile – 4 m

Ref: 1110/400

Galvanized U profile 30 x 30 mm - 4 m length.

View product
U-profile – 5 m

Ref: 1110/500

Galvanized U profile 30 x 30 mm - 5 m length.

View product
Jointing bracket

Ref: 1110M
- Jointing bracket for U profile 30 x 30
View product
U-profile – L = 6 m

Ref: 1110/600
- Galvanized U profile 30 x 30 mm - 6 m length
View product

Bottom guide

Ref: 1105
- Bottom guide on a hinge for U-profile 30 x 30 (Item Nr 1110)
View product
Offset bottom guide

Ref: 1105EL
- Offset bottom guide for U-profile 30 x 30 (Item Nr 1110)
View product

Angle steel

Ref: 5049

Angle steel, welding type (40 x 25) for curve. 710 mm long.

View product
